Panasonic FP2-C2 Counter Module

Panasonic FP2-C2 Counter Module

"FP2-C2" is a standard type CPU unit for the Panasonic FP2/FP2SH series of programmable logic controllers (PLCs), used in industrial automation. Its part number is AFP2231.
Product Type: CPU Unit for Programmable Logic Controller (PLC) systems.
Brand: Panasonic (Matsushita Electric Works).
Series: FP2SH.
Memory Size: 10K Words (60k steps).
Communication: Includes an RS-232C port for communication with external equipment like computers or display panels.
Mounting: Designed for backplane mounting.
Features: Includes battery backup.

Learn More, Email Me: henry@free-plc.com

FP2-C2 Power Supply user manual

Line Driver Differential Output Output  Provides differential outputs of encoder signals A, B and Z phases that come from the scaler.  Receive these signals with a line receivers. In this case, install a resistor of approx. 330Ω between the inputs. Outputs Z-phase signals among those from the encoder. The outputs are noninsulated.  Receive these signal with high-speed photo coupler at controller side, since these Z-phase signal width is normally narrow.
