Panasonic FP2-HSCT Counter Module

The Panasonic FP2-HSCT (part number AFP2441) is a 200kHz, 24V DC high-speed counter unit designed for the Panasonic FP2 PLC system. It features NPN output for industrial automation, control, and counting applications.
Type: High-speed counter unit
Brand: Panasonic
Model/Part Number: FP2-HSCT / AFP2441
Speed: 200kHz
Voltage: 24 V DC
Output Type: NPN
Compatibility: FP2 series programmable controllers

Learn More, Email Me: henry@free-plc.com

330105-02-12-05-02-00	ic697mem735	ABB KUC755AE105 3BHB005243R0105
330101-00-28-10-02-cn	125720-01	ABB PFSK151 3BSE018876R1
330103-00-03-10-02-cn	330100-50-00	ABB PFSK152 3BSE018877R2

FP2-HSCT Power Supply user manual

There exists a collector-to-emitter voltage VCE(SAT) of approx. 1.2V at transistor ON, because of Darlington connection of the output transistor. Note that normal TTL IC can't be directly connected since this does not meet VIL requirement. If the recommended current value of the actual photocoupler is 10mA, calculate the resistance using the formula below
