The Panasonic FP2-BP09 (also known by the part number AFP25009) is a 9-slot backplane/motherboard used in the Panasonic FP2 series of Programmable Logic Controllers (PLCs).
Type: PLC Backplane / Motherboard.
Manufacturer: Panasonic Industrial Automation Sales (or Nais).
Series: FP2 Series.
Slots: Designed as a 9-slot rack (standard type) for main or expansion use.
Function: Serves as the base unit for installing CPU modules, power supply units, and I/O modules, providing a reliable platform for advanced automation applications.
Dimensions: Approximately 10.4 in x 4.0 in x 1.0 in (26.4 cm x 10.2 cm x 2.5 cm).
Weight: Approximately 0 lbs 11.7 oz (0.3 kg).
