Panasonic FP2-AD8 PLC Programmable controller

Panasonic FP2-AD8  PLC Programmable controller

The FP2-AD8 is a specific model of an Analog Input Module for the Panasonic FP2 PLC series (FP2SH Programmable Logic Controllers), designed to convert analog signals (like voltage or current from sensors) into digital data for the PLC to process, offering features like high-speed conversion and support for various input types (voltage, current, temperature) across multiple channels (8-channel).
Key Features & Functions:
Analog-to-Digital Conversion: Converts real-world analog signals (from sensors, transducers) into digital values.
Multiple Channels: Provides 8 channels for input.
Versatile Inputs: Supports various inputs, including voltage (e.g., +/-10V, 1-5V) and current, with versions (like FP2-AD8X) supporting RTDs (PT100/1000) and thermocouples (S, J, K, T, R, N).
High-Speed: Offers fast conversion rates (e.g., 500 µs/channel).
Resolution: Converts to up to 16-bit digital data.
Compatibility: Integrates with Panasonic FP2/FP2SH PLC systems, functioning as an expansion unit.

Learn More, Email Me: henry@free-plc.com

FP2-AD8 Power Supply user manual

 Turn on your personal computer. Start Windows“ 95 (or 98). Turn on the amplifier.  Click on the start button of Windows“ (see the Windows“ manual). Select (click on) PANATERM“ from the program menu. An opening splash will be displayed for two seconds, and then PANATERM“ screen will appear. For the operation, functions and other details about PANATERM“, see the Instructions for the PANATERM“ program..
