Panasonic FP2-PP42 Motion Control Module

Panasonic FP2-PP42  Motion Control Module

The FP2-PP42 is a specific model number for a Multifunction Type Positioning Unit manufactured by Panasonic Industrial Automation Sales. It is a module used with the Panasonic FP2 and FP2SH series of Programmable Logic Controllers (PLCs) for motion control applications.
Type: Motion Control Module / Positioning Unit
Manufacturer Product Number (MPN): AFP2435
Axes Controlled: 4 axes (independent control)
Outputs: 4 pulse outputs
Output Mode Options: 1 Pulse output (Pulse/Sign) or 2 Pulse output (CW/CCW)
Mounting Type: Backplane
Supply Voltage: 24 V DC (21.6 V DC to 26.4 V DC range)
Max Speed Command Range: 1 pps (pulse per second) to 4 Mpps
Acceleration/Deceleration: Linear or S-curve acceleration/deceleration control is possible

Learn More, Email Me: henry@free-plc.com

FP2-PP42 Power Supply user manual

 You can conduct the following operations using PANATERM“:  Setting the Parameters for amplifier, storing them, and writing in the memory (EEPROM)  Monitoring input/output status, monitoring pulse input, monitoring load ratio. Checking current error status and error history. Measurement of wave form graphic data, and storage and reading of the data. Automatic tuning  Measurement of frequency characteristics.
