Panasonic FP2-AD8X Input Module

Panasonic FP2-AD8X Input Module

The FP2-AD8X is a specific model of Panasonic FP2 series analog input expansion module used in industrial automation for Programmable Logic Controllers (PLCs) that converts analog signals (like voltage or current from sensors) into digital data the controller can understand, often identified by part number AFP2401. These modules provide multiple analog input channels, expanding the capabilities of the main FP2 PLC system for monitoring real-world conditions.
Key Characteristics:
Brand: Panasonic
Series: FP2
Type: Analog Input Unit/Expansion Module
Function: Reads analog signals (e.g., from temperature, pressure sensors).
Part Number: Often associated with AFP2401.
Application: Industrial Automation, connected to Panasonic FP Series PLCs.
