Panasonic FP2-XY64D2T Output Module

Panasonic FP2-XY64D2T Output Module

The FP2-XY64D2T (Part Number: AFP23467) is a mixed Input/Output (I/O) expansion module manufactured by Panasonic Industrial Automation for use with the FP2 and FP2SH series Programmable Logic Controllers (PLCs).
Key Specifications
Module Type: Mixed I/O (Digital Input and Solid State Output).
I/O Count: 64 points total (32 Digital Inputs and 32 Solid State Outputs).
Output Type: Transistor (NPN/Sink).
Mounting Type: Backplane mounting.
Termination: Rectangular connector.
Operating Temperature: 0°C to 55°C.

Learn More, Email Me: henry@free-plc.com

FP2-XY64D2T  Power Supply user manual

 Before starting the measurement, make sure that the machine does not move beyond the limit. Approximate speed = Offset (r/min.)  0.017 x (Sampling rate + 1) With a larger offset value, good results can be obtained, though the speed becomes higher. Set-up Pr21 (Real time auto tuning mode set-up) to 0. Set-up the offset larger than the amplitude setting, and with one-way rotation so that you can obtain better results.
