Panasonic FP2-SDU Communications Module

Panasonic FP2-SDU Communications Module

The FP2-SDU is a Serial Data Unit (SDU), specifically a general communication module, for the Panasonic FP2 series of Programmable Logic Controllers (PLCs). This expansion unit allows the PLC system to interface and communicate with external devices via serial communication.
Product Details
Manufacturer: Panasonic Industrial Automation Sales.
Type: A communications module or serial interface module that serves as an expansion unit for the FP2/FP2SH series of PLCs.
Function: It adds serial data unit capabilities to the PLC system, enabling general communication functions. This allows the PLC to connect to a wider range of external equipment, such as computers or display panels, for data exchange and remote monitoring/maintenance.
System Integration: The unit is designed to be installed to the right of the power supply unit within the modular FP2 backplane system.
Status: According to some distributors, the FP2-SDU is an obsolete product and is no longer manufactured, though used or surplus units may still be available from various suppliers.
