Panasonic FP2-PP4 Motion Control Module

Panasonic FP2-PP4 Motion Control Module

The FP2-PP4 (Part Number: AFP2431) is a 4-axis positioning unit designed for use with the Panasonic (formerly NAiS) FP2/FP2SH series Programmable Logic Controllers (PLCs).
Key Specifications
Axis Support: Controls up to 4 axes of motion.
Module Type: Positioning/Motion Control module.
I/O Capacity: Typically features 64 input points and 64 output points.
Compatibility:
Used with Panasonic FP2 and FP2SH PLC processors.
Note: It is not compatible with the newer multi-function type FP2 positioning units.
Display Features: Includes an operation status display switch unique to this model.

FP2-PP4 Power Supply user manual

Check that the line amplifier is connected at the both sides. If the controller does not have a differential input.The motor produces an abnormal sound and/or vibration. Causes The gains are too large. The velocity detection filter is not proper. Resonance between the machine and motor occurs. Motor bearing Electromagnetic sound, gear sound, braking sound, hub sound, rubbing sound from the encoder. Operate the motor without load in order to check the sound and vibration near the bearing. Replace the motor and operate it to do the same checks. Repair the motor, if necessary. Operate the motor without load or use a new motor in order to locate the source of sounds. Repair the motor, if necessary.
