Panasonic FP2-SDU Communications Module

Panasonic FP2-SDU  Communications Module

The FP2-SDU is a communication module (also known as a Serial Data Unit or general communication module) manufactured by Panasonic Industrial Automation Sales for use with their FP2 and FP2SH series Programmable Logic Controllers (PLCs).
Product Details
Function: The FP2-SDU allows the FP2/FP2SH PLC system to communicate with external devices through general-purpose serial communication, computer links, or PLC links.
Compatibility: It is designed to be a component of the Panasonic FP2/FP2SH series of compact and high-performance PLCs.
Mounting: The module is a backplane-mounted communications module.
Connectivity: The unit allows for flexible communication options by potentially accepting up to two attachable communication blocks (such as RS-232C, RS-422, or RS-485 blocks).

Learn More, Email Me: henry@free-plc.com

FP2-SDU Power Supply user manual

If you want to improve the response further, adjust Pr15 (Velocity Feed Forward) within the extent that the motor (machine) does not generate abnormal sound or vibration. • With a larger value, overshoot and/or chattering of in-position signals may occur, which results in a longer in-position time. Note that this may be improved by adjusting the value of Pr16 (Feed Forward Filter).
