Panasonic FP2-C3P Programmable Logic Controller

Panasonic FP2-C3P Programmable Logic Controller

The FP2-C3P (part number AFP2255) is a Central Processing Unit (CPU) module for the Panasonic (formerly NAIS/Matsushita) FP2/FP2SH series of programmable logic controllers (PLCs). It is a medium-to-large scale control unit designed for industrial automation tasks that require high-speed processing and substantial program memory.
Key Specifications
Series: FP2 / FP2SH.
Program Capacity: 120k steps, making it one of the higher-capacity units in the FP2 family.
Memory Type: Equipped with an IC memory card interface for expanded storage and program management.
Communication: Includes a standard RS-232C port for programming and data exchange.
Capabilities:
Supports high-speed counter inputs (up to 100kHz) and pulse/PWM outputs for motion control.

Learn More, Email Me: henry@free-plc.com

FP2-C3P Power Supply user manual

Set the rotary switch depending on machine configuration. Then while checking movement of machine, increase the rotary switch value one by one. Relationship between Gain Adjustment Rotary Switch Value and Inertia. Set the rotary switch to "0" position when setting automatic gain tuning or parameters. Set up the RSW to "0" when using the 2nd gain. When the number gets larger, gain will be increased. *Do not operate rapid change of the value such as 9 to 0 or 0 to 9. Otherwise the motor will oscillate, which results in abnormal sound and vibration.
