Panasonic FP2-AD8VI Input Module

Panasonic FP2-AD8VI Input Module

The FP2-AD8VI is an obsolete but common Panasonic analog input module for their FP2/FP2SH series PLCs, featuring 8 non-isolated channels for voltage (e.g., +/-10V) or current (e.g., 4-20mA) signals, providing essential data acquisition for industrial automation systems, with screw terminals for wiring and built for rugged use, though newer replacements are available.
Key Features & Specifications:
Type: Analog Input Module (PLC Expansion Unit).
Manufacturer: Panasonic Industrial Automation / Sunx.
Channels: 8 Analog Inputs.
Signal Types: Supports Voltage (e.g., +/-10V, 1-5V) and Current (e.g., 4-20mA, +/-20mA).
Resolution: High-resolution conversion (e.g., 13/16-bit) for accuracy.
Connectivity: Screw terminal connections (M3.5).
Compatibility: Designed for Panasonic FP2 and FP2SH PLC series.
Status: Discontinued (Obsolete) and replaced by newer models, but still found on the surplus market.

FP2-AD8VI Power Supply user manual

The FP0-TC4 and FP0-TC8 thermocouple units are suitable for user friendly temperature acquisition using standard thermocouples with high precision. Up to three units can be added to each control unit, enabling temperature control of up to 24 channels. The temperature data obtained using the thermocouple is converted to the digital value to be read into the FP0 control unit. Standard types of thermocouples can be used: K, J, T and R.Temperature measurement ranges are available.
