The Panasonic FP0-TC4 is a thermocouple input expansion unit for the Panasonic FP0 and FPΣ series of Programmable Logic Controllers (PLCs). It allows for user-friendly and high-precision temperature acquisition for industrial automation and process monitoring applications.
Key Specifications
Function: Thermocouple input expansion unit for PLCs.
Channels: 4 input channels for temperature measurement.
Thermocouple Types: Compatible with standard K, J, T, and R type thermocouples. It also supports S, B, E, and N types according to IK Automation.
Resolution: 0.1 degree Celsius.
Output Data: Temperature data is converted to digital values and can be set to display in degrees Celsius or Fahrenheit inside the unit.
Features: Includes an averaging function for stable input signals and detection of broken thermocouples.
Mounting: Designed for DIN Rail mounting.
Termination Style: Pluggable screw terminals for wiring.

FP0-TC4  Power Supply user manual

By using C-NET, you can use multiple FP0s as data collection terminals. By using the C-NET network and exclusive adapters, you can connect multiple FP0s by multi-drop connection with 2-wire cables. You can use computers for separate control or have network terminals for a centralized management system.
