PanasonicFP2-AD8X Input Module

PanasonicFP2-AD8X Input Module

FP2-AD8X (also known by the part number AFP2401) is a high-performance Analog Input Unit for the Panasonic FP2 series Programmable Logic Controllers (PLCs).
Key Technical Specifications
Channels: 8 analog input channels.
Resolution: 13/16-bit high-resolution conversion.
Input Types: Supports multiple ranges including voltage (±10V, 1-5V), temperature sensors (PT100/1000), and thermocouples.
Series Compatibility: Designed specifically for use with the Panasonic FP2 and FP2SH series controllers.
Physical Form: Standard expansion module that connects to the PLC backplane.

FP2-AD8X  Power Supply user manual
