Panasonic FPOR-C32CT Programmable Logic Controller

Panasonic FPOR-C32CT Programmable Logic Controller

The FP0R-C32CT is a Panasonic control unit within the FP0R series of programmable logic controllers (PLCs), featuring 32 I/O points (16 inputs and 16 transistor outputs). It is a compact, high-speed controller designed for industrial automation applications.
Item     Specifications
Rated Voltage    24 V DC
I/O Points    32 points (16 inputs, 16 transistor outputs)
Output Type    Open collector (NPN)
Max. Load Current    0.2 A per point
Program Memory    EEPROM (no backup battery required for program/system register)
Program Capacity    32 k steps
Operation Speed    0.08 µs/step for basic instructions (first 3000 steps)
Communication Port    One RS-232C port (3P terminal block)
Dimensions    Approx. 90 mm H x 25 mm W

Learn More, Email Me: henry@free-plc.com

FPOR-C32CT  Power Supply user manual

Connect to the grounding system of the facility. Never fail to connect between the amplifier's protective earth terminal and control board's protective earth terminal (ground plate) in order to avoid electric shocks. Ensure to connect matching in color between the motor wires and terminals.Don't short circuit or ground. Don't connect to the main power.The electromagnetic brake is not polar-sensitive.
