Panasonic FP2-Y64T Output Module

Panasonic FP2-Y64T  Output Module

The Panasonic FP2-Y64T (Part Number: AFP23407) is an obsolete Output Unit for the FP2 series of Programmable Logic Controllers (PLCs). It provides 64 solid-state NPN transistor outputs for industrial automation applications
Output Type: Transistor (NPN open collector/sink).
Number of Outputs: 64 points (solid-state).
Rated Voltage: 5V to 24V DC.
Output Current: 0.1 A (100 mA) at 12–24V DC, and 50 mA at 5V DC.
Connection Type: Rectangular connector.
Mounting: Backplane.
Operating Temperature: 0°C to 55°C.
Weight: Approximately 0.265 lb (120.2 g).

Learn More, Email Me: henry@free-plc.com

FP2-Y64T Power Supply user manual

 Make sure that the cables are not subjected to moments or vertical loads due to external bending forces or self-weight at the cable outlets or connections. In case the motor is movable, secure the cable (proper one supplied together with the motor) to a stationery part and it should be extended with an additional cable which should be housed in a cable bearer so that bending stresses can be minimized.  Make the bending radius of cables as large as possible.
