Panasonic FP2-PN4AN Electronics Automation

Panasonic FP2-PN4AN Electronics Automation

Type: RTEX (Realtime Express) positioning unit (intelligent unit).
Number of Axes Controlled: 4 axes.
Compatibility: Designed for use with the Panasonic FP2 and FP2SH series PLCs.
Communication: High-speed 100 Mbps communications.
Features: Supports 3-axis helical interpolation in addition to 2-axis linear and circular interpolation functions. It is compatible with the MINAS A4N series servo systems.
Tool Software: Uses the dedicated "Configurator PM" software for setup and monitoring.
Click here, view our Blog.

FP2-PN4AN Power Supply user manual

(For transistor output type only) The unit comes equipped with 2 channels for the output of up to 10kHz pulses (5kHz during 2-channel output). Since these two channels can be separately controlled, the PLC is also suitable for independent 2-axis positioning. Setting automatic trapezoid control, automatic return to home position and JOG operation are made very easy by using instructions specially designed for such operations.
