Panasonic FP2-DA4 Output Module

Panasonic FP2-DA4  PLC Programmable controller

The FP2-DA4 (also known by part number AFP2410) is a 4-channel analog output unit designed for the Panasonic (formerly NAiS/Matsushita) FP2 and FP2SH series Programmable Logic Controllers (PLCs).
Key Specifications
Channels: 4 analog output channels.
Resolution: 12-bit.
Output Ranges: Supports ±10V voltage signals and 0–20mA current signals.
Mounting: Backplane mounting with screw terminal connections.
Compatibility: Used with FP2 and FP2SH series CPU units.
Operating Temperature: 0°C to 55°C.

Learn More, Email Me: henry@free-plc.com

FP2-DA4 Power Supply user manual

 Start the motor.  If the fluctuation in load inertia is small, stop the motor (machine), and set Pr21 to 0 to fix the gain (in order to raise the safety). FDownload the obtained gain values to EEPROM. Note that if you turn off the power before downloading, the gain values will be lost. Before changing Pr21 or Pr22, stop (servo-lock) the motor.  Don't modify Pr10 through Pr15. Otherwise it may give a shock to the machine.
