The FP2-C1 (also known by part number AFP2211) is a standard CPU unit for the Panasonic FP2 series of programmable logic controllers (PLCs). It is used in industrial automation and motion control applications to manage and control various manufacturing processes.
Key Specifications
Manufacturer: Panasonic (Matsushita Electric)
Product Type: CPU Unit (Central Processing Unit) for the FP2/FP2SH PLC series
Part Number: AFP2211
Control Method: Relay program/control method
I/O Points: Supports up to a maximum of 512 I/O points
Program Capacity: 16k steps standard, with expansion memory for up to 32k steps
Operation Speed: 350 ns/step for basic instructions
Networking: Supports various networking and communication functions including S-LINK, Ethernet, and Fieldbus options
Mounting Type: Panel mount
Dimensions: The front face area is 140 mm (5.512 inch) wide and 100 mm (3.937 inch) high.
Usage: The unit is designed for industrial applications requiring sequencing, positioning control, analog control, and communication functions.

FP2-C1  Power Supply user manual

If the command pulses are deformed or narrowed, adjust the pulse generation circuit. Take measures to reduce the noise on the command pulse. Check the amount of position error on the monitor screen of PANATERM“. Increase the value of Pr10 to the extent that no oscillation occurs. Decrease the value of Pr60 (in-position range) to the extent that the in-position signals do not chatter.
