Panasonic FP0-C32P Electronics Automation

Panasonic FP0-C32P  Electronics Automation

The FP0-C32P is a compact Programmable Logic Controller (PLC) control unit within the FP0 series manufactured by Panasonic (formerly Matsushita Electric Works). It is designed for small-scale industrial automation where space-saving is a priority.
Key Specifications
I/O Capacity: Total of 32 points, consisting of 16 digital inputs (24V DC) and 16 transistor outputs.
Output Type: PNP open collector (Source type).
Memory: Built-in EEPROM with a program capacity of 5k steps.
Power Supply: Requires 24V DC (range of 19.6V to 26.4V) with a rated current of approximately 0.3A.
Dimensions: Ultra-compact design, typically measuring 30mm in width for 32 I/O models.

FP0-C32P Power Supply user manual

After a trip event, the status LED (STATUS) on the front panel will be turned in red, and the alarm code LED display (ALM CODE) will start flashing. No servo-ON occurs. For meaning of flashing of alarm code LED, see page 49.  Any trip status can be cleared by keeping A-CLR (Alarm Clear Input) on for at least 120 ms. The overload protection can be cleared by A-CLR at least 10 seconds after the occurrence of the event. If the main power supply of amplifier turns off, the time limiting operation is cleared.The alarms mentioned above can also be cleared by using PANATERM“.
