General Electric IC660BLA103 Thermocouple Input Block

General Electric Thermocouple Input Block

Item No.:
General Electric IC660BLA103
Payment:
T/T
Product origin:
USA
Color:
Mental
Goods_stock:
100
Shipping port:
HongKong
Lead Time:
1-2 Days

Product Details

General Electric IC660BLA103 Thermocouple Input Block

The power input terminal board has four terminals. The top two (L1 and N) are for 120/ 240 VAC or 125 VDC input power connections; the third and fourth terminals are for ground and overvoltage protection device connections, respectively. Power input con- nections should be made with copper AWG #16 (1.3 mm 2 ) wire rated for 75 ? C (167 ? F). Each terminal can accept solid or stranded wires, but the wires into any given terminal should be the same type and size. It is recommended that the ground terminal on the power supply be connected to the GND terminal on the rack and to earth using copper AWG #12 (3.3 mm 2 ) wire rated for 75 ? C (167 ? F) to ensure adequate
grounding.
