Allen Bradley 1771-OFE2K Analog Output Module

Allen Bradley Analog Output Module

Item No.:
Allen Bradley 1771-OFE2K
Payment:
T/T
Product origin:
Sweden (SE)
Color:
Mental
Goods_stock:
999
Shipping port:
HongKong
Lead Time:
1-2 Days

Product Details

Allen Bradley 1771-OFE2K Analog Output Module

Connections to the output module are made to the field wiring arm (cat. no. 1771-WH) shipped with the module. An optional fused field wiring arm is available (cat. no. 1771-WHF) which provides individual fusing for each circuit. Attach the field wiring arm to the pivot bar on the bottom of the I/O chassis. The field wiring arm pivots upward and connects with the module so you can install or remove the module without disconnecting the wires. Refer to Figure 1. You must supply ac (L1) at terminals A through D on the field wiring arm. You need four ac connections to accommodate the total required surge rating on the module without overstressing any single connection on the field wiring arm. Jumper all ac (L1) connections together to prevent module damage.

Allen Bradley 1771-OFE2K Analog Output Module Technical drawing:

AI825
