Allen Bradley 1771-ODD Digital AC Output Module

Allen Bradley Digital AC Output Module

Item No.:
Allen Bradley 1771-ODD
Payment:
T/T
Product origin:
Sweden (SE)
Color:
Mental
Goods_stock:
999
Shipping port:
HongKong
Lead Time:
1-2 Days

Product Details

Allen Bradley 1771-ODD Digital AC Output Module

An output from this module can drive an Allen-Bradley Size 5 motor starter, provided its supply voltage does not drop below 92V ac. The maximum load current the module can deliver is 2A per channel, not to exceed 8A total per module.The switching device in the output circuit is a solid-state triac. There is a small leakage current in the off state due to both triac and capacitive characteristics. The maximum leakage current per output is 3mA at 138V ac. Nominal leakage current is 1.5mA. The on-state voltage drop across the output terminals will not exceed 1.5V ac at 2A.

Contact: fay@free-plc.com

Allen Bradley 1771-ODD Digital AC Output Module Technical drawing:
