Allen Bradley 1771-OD Isolated Output Module

Allen Bradley Isolated Output Module

Item No.:
Allen Bradley 1771-OD
Payment:
T/T
Product origin:
Sweden (SE)
Color:
Mental
Goods_stock:
999
Shipping port:
HongKong
Lead Time:
1-2 Days

Product Details

Allen Bradley 1771-OD Isolated Output Module

An output from this module can drive an Allen–Bradley Size 5 motor starter, provided its supply voltage does not drop below 105V ac. The maximum load current the module can deliver is 2A per channel, not to exceed 6A total per module. The switching device in the output circuit is a triac. There is a small leakage current in the off state due to both triac and capacitive characteristics. The maximum leakage current per output is 5mA at 138V ac. Nominal leakage current is 1mA. The on–state voltage drop across the output terminals is no more than 2.0V ac at 100mA.The ac output module is shipped in a static–shielded bag to guard against electrostatic discharge damage. Observe the following precautions when handling the module.

Allen Bradley 1771-OD Isolated Output Module Technical drawing:

330930-045-00-00
