Allen Bradley 1756-PA72 Standard Power Supply Module

Allen Bradley Standard Power Supply Module

Item No.:
Allen Bradley 1756-PA72
Payment:
T/T
Product origin:
Sweden (SE)
Color:
Mental
Goods_stock:
999
Shipping port:
HongKong
Lead Time:
1-2 Days

Product Details

Allen Bradley 1756-PA72 Standard Power Supply Module

The following graphs show the input power requirements for the power supplies, given the power they are providing to the modules in the chassis.Follow these steps to determine the power requirements for you chassis. Calculate the Backplane Power Load by adding the power draw (in Watts) for all of the planned modules. For module power draws, refer to the module specification tables in the ControlLogix Selection Guide, publication 1756-SG001.Locate the Backplane Power Load on the graph’s vertical (y) axis and determine the corresponding Real Power (input-power) rating on the horizontal (x) axis. The Real Power value is the amount of power consumed by the power supply.

Allen Bradley 1756-PA72 Standard Power Supply Module Technical drawing:
